Build your own workshop cabinet with these CNC-ready DXF files and organize your workshop in style.
This simple workshop cabinet comes in three widths (400mm, 475mm, and 550mm), making it easy to mix, match, and customize your layout.
The design comes with built-in drawer slides that are super simple to install and allow you to save money on metal drawer slides.
Ideal for tool storage, supplies, or gear. Designed for CNC routers - no design work needed.
Perfect for plywood builds - fast, functional, and workshop-friendly.
Supported CNC sizes
Supported CNC sizes
Max single piece size
Max single piece size
So if it can fit on your CNC router, you can build this project
Dimensions
Dimensions
Minimum
Width | Length | Height |
---|---|---|
400 mm | 550 mm | 900 mm |
15¾ inch | 21⅝ inch | 35⅜ inch |
Maximum
Width | Length | Height |
---|---|---|
550 mm | 550 mm | 900 mm |
21⅝ inch | 21⅝ inch | 35⅜ inch |
Required materials
Required materials
For a 820 x 1220 mm (2.6 x 4 ft) CNC:
- 3 sheets of 1220 x 820 x 18 mm (48 x 32 x 3/4 inches) plywood
- 3 sheets of 1220 x 700 x 12 mm (48 x 28 x 1/2 inches) plywood
- 6 mm (1/4 inch) router bit
- 35 mm (1-1/4 inch) wood screws
- 12 mm (1/2 inch) wood screws
- full-overlap cabinet hinges - 2 pieces
- shelf support pins
For a 1220 x 1220 mm (4 x 4 ft) CNC:
- 1 sheet of 1220 x 1220 x 18 mm (48 x 48 x 3/4 inches) plywood
- 1 sheet of 1220 x 750 x 18 mm (48 x 30 x 3/4 inches) plywood
- 1 sheet of 1220 x 1220 x 12 mm (48 x 48 x 1/2 inches) plywood
- 1 sheet of 750 x 600 x 12 mm (30 x 24 x 1/2 inches) plywood
- 6 mm (1/4 inch) router bit
- 35 mm (1-1/4 inch) wood screws
- 12 mm (1/2 inch) wood screws
- full-overlap cabinet hinges - 2 pieces
- shelf support pins
For a 1220 x 2440 mm (4 x 8 ft) CNC:
- 1 sheet of 2440 x 1220 x 18 mm (96 x 48 x 3/4 inches) plywood
- 1 sheet of 2440 x 800 x 12 mm (96 x 32 x 1/2 inches) plywood
- 6 mm (1/4 inch) router bit
- 35 mm (1-1/4 inch) wood screws
- 12 mm (1/2 inch) wood screws
- full-overlap cabinet hinges - 2 pieces
- shelf support pins
