Wall Shelf - 2 x 2 Cubes DXF Files

Wall Shelf - 2 x 2 Cubes DXF Files

Regular price $9.35 USD
Regular price $0.00 USD Sale price $9.35 USD
Sale Sold out
Taxes included.

This shelf will help you turn an empty wall into a place where to store and display your proudest possessions.


The design can be cut on a 900 x 1200 mm (3 x 4 ft) CNC router and bigger.


*The files are adjusted to fit both metric and imperial standards for materials and tools


Dimensions:

700 mm (height) x 700 mm (length) x 250 mm (depth)

27-1/2 inches (height) x 27-1/2 inches (length) x 10 inches (depth)


Required materials:

For a 900 x 1200 mm (3 x 4 ft) CNC

  • 1 sheet of 1100 x 750 x 15 mm (43-1/2 x 29-1/2 x 5/8 inches) plywood
  • 1 sheet of 730 x 530 x 15 mm (28-3/4 x 21 x 5/8 inches) plywood
  • 1 sheet of 730 x 730 x 6 mm (29 x 29 x 1/4 inches) plywood
  • 4 mm (1/8 inch) router bit

For a 1200 x 1200 mm (4 x 4 ft) CNC

  • 1 sheet of 1100 x 1000 x 15 mm (43-1/2 x 39-3/8 x 5/8 inches) plywood
  • 1 sheet of 730 x 300 x 15 mm (28-3/4 x 12 x 5/8 inches) plywood
  • 1 sheet of 730 x 730 x 6 mm (29 x 29 x 1/4 inches) plywood
  • 4 mm (1/8 inch) router bit

For a 1250 x 2500 mm (4 x 8 ft) CNC

  • 1 sheet of 1450 x 800 x 15 mm (57 x 31-1/2 x 5/8 inches) plywood
  • 1 sheet of 730 x 730 x 6 mm (29 x 29 x 1/4 inches) plywood
  • 4 mm (1/8 inch) router bit

Assembling time:

25 minutes


Delivery time:

30 seconds

After completing the order, you will receive the DXF design file in your email within seconds.


Updates:

Free

If your plywood sheet is thicker or thinner than expected, send the number of your purchase and the actual thickness to contact@aribabox.com. We will send you the updated DXF design file for free.


The product may differ from the representative images when cut and assembled. We hope you will enjoy your purchase from Aribabox.


Supported CNC sizes

The project can be made on a 900 x 1200 mm (3 x 4 ft) CNC router and bigger.

Dimensions

250 mm (width) X 700 mm (length) X 700 mm (height)
9.8 inches (width) X 27.6 inches (length) X 27.6 inches (height)

Required materials

For a 900 x 1200 mm (3 x 4 ft) CNC
- 1 sheet of 1100 x 750 x 15 mm (43-1/2 x 29-1/2 x 5/8 inches) plywood
- 1 sheet of 730 x 530 x 15 mm (28-3/4 x 21 x 5/8 inches) plywood
- 1 sheet of 730 x 730 x 6 mm (29 x 29 x 1/4 inches) plywood
- 4 mm (1/8 inch) router bit
For a 1200 x 1200 mm (4 x 4 ft) CNC
- 1 sheet of 1100 x 1000 x 15 mm (43-1/2 x 39-3/8 x 5/8 inches) plywood
- 1 sheet of 730 x 300 x 15 mm (28-3/4 x 12 x 5/8 inches) plywood
- 1 sheet of 730 x 730 x 6 mm (29 x 29 x 1/4 inches) plywood
- 4 mm (1/8 inch) router bit
For a 1250 x 2500 mm (4 x 8 ft) CNC
- 1 sheet of 1450 x 800 x 15 mm (57 x 31-1/2 x 5/8 inches) plywood
- 1 sheet of 730 x 730 x 6 mm (29 x 29 x 1/4 inches) plywood
- 4 mm (1/8 inch) router bit

Assembling time

25 minutes
The product may differ from the representative images when cut and assembled. We hope you will enjoy your purchase from Aribabox!
