Ultimate Miter Saw Station - DXF Files

Ultimate Miter Saw Station - DXF Files

$29.95 USD
$29.95 USD $29.95 USD
Sale Sold out
Taxes included.

Upgrade your workshop with a miter saw station designed for better workflow, organization, and everyday use.



This CNC-cut design combines a dedicated miter saw workspace, integrated storage, dust collection support, and a movable center cabinet for handling longer workpieces.



The CNC files include everything needed to build your own miter saw station and customize it to fit your workshop.



Build a cleaner, more capable workspace with a station made for real workshop use.



Designed to match the heights with Workshop Cabinet Set as well as The Modular Cabinets



Width of the middle section: 500 mm (19.7 inches)

Distance from the cabinet front to the fence: 345 mm(13.6 inches)

Height for the miter saw platform: 85 mm (3.35 inches)

Supported CNC sizes

The project can be made on a 1200 x 1200 mm (4 x 4 ft) CNC router and bigger.

Max single piece size

The biggest component is 940 x 920 mm (37.01 x 36.22 inches).
So if it can fit on your CNC router, you can build this project

Dimensions

Width Length Height
1200 mm 940 mm 918 mm
47¼ inch 37 inch 36⅛ inch

Required materials

For a 1220 x 1220 mm (4 x 4 ft) CNC
- 2 sheets of 1220 x 1220 x 12 mm (48 x 48 x 1/2 inches) plywood
- 4 sheets of 1220 x 1220 x 18 mm (48 x 96 x 3/4 inches) plywood
- 2 sheets of 1220 x 900 x 18 mm (48 x 36 x 3/4 inches) plywood
- 1 sheet of 1220 x 500 x 18 mm (48 x 20 x 3/4 inches) plywood
- Aribabox Fixed Caster wheels - 4 pieces
- 45-degree cabinet hinges - 4 pieces
- regular cabinet hinges - 6 pieces
- 15 mm (5/8 inch) wood screws - 40 pieces
- 30 mm (1-1/4 inches) wood screws - 160 pieces
- M8 Tee Nut - 4 pieces
- M8 x 60 screws - 4 pieces
- 6 mm (1/4 inch) router bit
For a 1220 x 2440 mm (4 x 8 ft) CNC
- 1 sheet of 1220 x 2440 x 12 mm (48 x 96 x 1/2 inches) plywood
- 3 sheets of 1220 x 2440 x 18 mm (48 x 96 x 3/4 inches) plywood
- Aribabox Fixed Caster wheels - 4 pieces
- 45-degree cabinet hinges - 4 pieces
- regular cabinet hinges - 6 pieces
- 15 mm (5/8 inch) wood screws - 40 pieces
- 30 mm (1-1/4 inches) wood screws - 160 pieces
- M8 Tee Nut - 4 pieces
- M8 x 60 screws - 4 pieces
- 6 mm (1/4 inch) router bit

Approximate CNC time

3 hours

Assembling time

4 hours
The product may differ from the representative images when cut and assembled. We hope you will enjoy your purchase from Aribabox!
