Modular Workshop Cabinet - Small with 1 Drawer - DXF Files

Modular Workshop Cabinet - Small with 1 Drawer - DXF Files

$2.95 USD
$5.95 USD $2.95 USD
Sale Sold out
Taxes included.

Upgrade your workshop with this modular CNC-friendly cabinet system designed for makers who want efficiency, flexibility, and smart storage.



These DXF files allow anyone with a CNC router to cut and assemble a ¼-height workshop cabinet module - perfect for customizing your setup one unit at a time.



Each module features a smooth, slide-free wooden drawer that requires no metal hardware, keeping the build simple and reliable. The system is fully modular, letting you stack and combine different sections to create a storage solution that fits your workflow.



This small module is available in three widths - 550 mm, 475 mm, and 400 mm - making it easy to mix and match with standard-size workshop cabinets (900 mm height).



Ideal for CNC hobbyists, woodworkers, and anyone building a clean, organized workshop.

Supported CNC sizes

The project can be made on a 600 x 600 mm (2 x 2 ft) CNC router and bigger.

Max single piece size

The biggest component is 550 x 550 mm (21.65 x 21.65 inches).
So if it can fit on your CNC router, you can build this project

Dimensions


Minimum

Width Length Height
400 mm 550 mm 225 mm
15¾ inch 21⅝ inch 8⅞ inch

Maximum

Width Length Height
550 mm 550 mm 225 mm
21⅝ inch 21⅝ inch 8⅞ inch

Required materials

For a 600 x 900 mm (2 x 3 ft) CNC
- 2 sheets of 600 x 900 x 18 mm (24 x 36 x 3/4 inches) plywood
- 2 sheets of 600 x 900 x 12 mm (24 x 36 x 1/2 inches) plywood
- 35 mm (1-1/2 inches) wood screws - 45 pieces
- 6 mm (1/4 inch) router bit
For a 900 x 1220 mm (3 x 4 ft) CNC and bigger
- a sheet of 700 x 1220 x 18 mm (28 x 48 x 3/4 inches) plywood
- a sheet of 800 x 1220 x 12 mm (32 x 48 x 1/2 inches) plywood
- a sheet of 550 x 250 x 12 mm (22 x 11 x 1/2 inches) plywood
- 35 mm (1-1/2 inches) wood screws - 45 pieces
- 6 mm (1/4 inch) router bit

Approximate CNC time

25 minutes

Assembling time

20 minutes
The product may differ from the representative images when cut and assembled. We hope you will enjoy your purchase from Aribabox!
