Modular Workshop Cabinet - Medium with 4 Drawers - DXF Files

Modular Workshop Cabinet - Medium with 4 Drawers - DXF Files

$3.95 USD
$7.95 USD $3.95 USD
Sale Sold out
Taxes included.

Create a versatile workshop storage solution with our Modular Workshop Cabinet - Medium with 4 Drawers DXF files.



Designed for CNC routers, this project lets you build modular cabinet sections that stack as you like.



This medium module is 2/4 the height of a standard 900 mm cabinet and includes four built-in drawers - no drawer slides needed.



Available in three widths (550 mm, 475 mm, 400 mm), it’s perfect for customizing your workshop setup.



Efficient, modular, and easy to assemble, this cabinet module keeps your tools organized while maximizing workspace.

Supported CNC sizes

The project can be made on a 600 x 600 mm (2 x 2 ft) CNC router and bigger.

Max single piece size

The biggest component is 550 x 550 mm (21.65 x 21.65 inches).
So if it can fit on your CNC router, you can build this project

Dimensions


Minimum

Width Length Height
400 mm 550 mm 430 mm
15¾ inch 21⅝ inch 16⅞ inch

Maximum

Width Length Height
550 mm 550 mm 430 mm
21⅝ inch 21⅝ inch 16⅞ inch

Required materials

For a 600 x 900 mm (2 x 3 ft) CNC
- 2 sheets of 600 x 900 x 18 mm (24 x 36 x 3/4 inches) plywood
- 1 sheet of 300 x 600 x 18 mm (12 x 24 x 3/4 inches) plywood
- 5 sheets of 600 x 900 x 12 mm (24 x 36 x 1/2 inches) plywood
- 35 mm (1-1/2 inches) wood screws - 75 pieces
- 6 mm (1/4 inch) router bit
For a 900 x 1220 mm (3 x 4 ft) CNC
- 1 sheet of 900 x 1220 x 18 mm (36 x 48 x 3/4 inches) plywood
- 1 sheet of 250 x 600 x 18 mm (10 x 18 x 3/4 inches) plywood
- 3 sheets of 830 x 1220 x 12 mm (34 x 48 x 1/2 inches) plywood
- 35 mm (1-1/2 inches) wood screws - 75 pieces
- 6 mm (1/4 inch) router bit
For a 1220 x 1220 mm (4 x 4 ft) CNC
- a sheet of 1000 x 1220 x 18 mm (40 x 48 x 3/4 inches) plywood
- 1 sheet of 1220 x 1220 x 12 mm (48 x 48 x 1/2 inches) plywood
- 1 sheet of 600 x 1220 x 12 mm (24 x 48 x 1/2 inches) plywood
- 35 mm (1-1/2 inches) wood screws - 75 pieces
- 6 mm (1/4 inch) router bit
For a 1220 x 2440 mm (4 x 8 ft) CNC
- a sheet of 1000 x 1220 x 18 mm (40 x 48 x 3/4 inches) plywood
- 1 sheet of 1000 x 2440 x 12 mm (40 x 96 x 1/2 inches) plywood
- 35 mm (1-1/2 inches) wood screws - 75 pieces
- 6 mm (1/4 inch) router bit

Approximate CNC time

30 minutes

Assembling time

25 minutes
The product may differ from the representative images when cut and assembled. We hope you will enjoy your purchase from Aribabox!
View full details
