Kids kitchen cooker DXF file
Kids kitchen cooker DXF file
Couldn't load pickup availability
The design can be cut on a 600 x 900 (2 x 3 ft) CNC router and bigger.
After completing the order, you will receive DXF files with component layout adjusted to different CNC sizes:
600 x 900 (2 x 3 ft)
900 x 1200 (3 x 4 ft)
1200 x 1200 (4 x 4 ft)
1200 x 2400 (4 x 8 ft)
*The files are adjusted to fit both metric and imperial standards for materials and tools
Dimensions:
540 mm (height) x 400 mm (length) x 340 mm (width)
21-17/64 (height) x 15-3/4 (length) x 13-25/64 (width)
Required materials:
For 600 x 900 (2 x 3 ft) CNC
- 3 sheets of 600 x 900 x 12 mm (23-5/8 x 35-7/16 x 1/2 inches) plywood
- 1 sheet of 400 x 310 x 12 mm (15-¾ x-12-13/64 x 1/2 inches) plywood
- 4 mm (3/16 inch) router bit for dogbones
- Magnets for door fixation
For 900 x 1200 (3 x 4 ft) CNC
- 1 sheet of 900 x 1200 x 12 mm (35-7/16 x 47-¼ x 1/2 inches) plywood
- 1 sheet of 620 x 900 x 12 mm (24-13/32 x 35-7/16 x 1/2 inches) plywood
- 4 mm (3/16 inch) router bit for dogbones
- Magnets for door fixation
For 1200 x 1200 (4 x 4 ft) CNC
- 1 sheet of 1200 x 1200 x 12 mm (47-¼ x 47-¼ x 1/2 inches) plywood
- 1 sheet of 310 x 310 x 12 mm (12-13/64 x 12-13/64 x 1/2 inches) plywood
- 4 mm (3/16 inch) router bit for dogbones
- Magnets for door fixation
For 1220 x 2440 (4 x 8 ft) CNC
- 1 sheet of 1220 x 1400 x 12 mm (48-1/32 x 55-⅛ x ½ inches) plywood
- 4 mm (3/16 inch) router bit for dogbones
- Magnets for door fixation
Assembling time:
15 minutes
Delivery time:
30 seconds
After completing the order, you will receive the DXF design file to your email within seconds.
Updates:
Free
If your plywood sheet is thicker or thinner than expected, send the number of your purchase and the actual thickness to contact@aribabox.com. We will send you the updated DXF design file for free.
The product may differ from the representative images when cut and assembled. We hope you will enjoy your purchase from Aribabox.
