Frame Clamping Jig DXF Files
Frame Clamping Jig DXF Files
Regular price
$7.45 USD
Regular price
$7.45 USD
Sale price
$7.45 USD
Unit price
/
per
Taxes included.
Couldn't load pickup availability
Simplify gluing picture frames with this CNC-cut clamping jig, designed for perfect alignment using just one quick clamp.
This jig can handle frames up to 1m (39 inches) diagonally, making it ideal for DIY enthusiasts and professionals seeking precision and efficiency.
Download now to streamline your workflow and elevate your project quality!
*The files are adjusted to fit both metric and imperial standards for materials and tools
Supported CNC sizes
Supported CNC sizes
The project can be made on a
600 x 900 mm (2 x 3 ft) CNC
router and bigger.
Max single piece size
Max single piece size
The biggest component is
530
x
45
mm (20.87
x
1.77
inches).
So if it can fit on your CNC router, you can build this project
So if it can fit on your CNC router, you can build this project
Dimensions
Dimensions
| Width | Length | Height |
|---|---|---|
| 135 mm | 530 mm | 60 mm |
| 5⅜ inch | 20⅞ inch | 2⅜ inch |
Required materials
Required materials
For a 600 x 900 mm (2 x 3 ft) CNC and bigger
- A sheet of 625 x 400 x 15 mm (25 x 16 x 5/8 inches) plywood
- M8 x 30 mm screws - 4 pieces
- M8 x 60 mm screws - 4 pieces
Approximate CNC time
Approximate CNC time
20 minutes
Assembling time
Assembling time
25 minutes
The product may differ from the representative images when cut and assembled. We hope you will enjoy your purchase from Aribabox!
