Double Box Shelf DXF Files

Double Box Shelf DXF Files

$14.45 USD
$14.45 USD $14.45 USD
Sale Sold out
Taxes included.

Downloadable DXF file for CNC routers to make a Double Box Shelf - a sturdy, space-saving rack that holds 18 plywood storage boxes.



Perfect for organizing toys, craft supplies, or household items. Originally designed for a kids' playroom, it fits seamlessly in garages, workshops, or living spaces. Easy-to-cut, easy-to-assemble - ideal for plywood.

Supported CNC sizes

The project can be made on a 900 x 1200 mm (3 x 4 ft) CNC router and bigger.

Dimensions

Width Length Height
1050 mm 700 mm 715 mm
41⅜ inch 27½ inch 28⅛ inch

Required materials

For 900 x 1200 mm (3 x 4 ft) CNC
- 6 sheets of 900 x 1200 x 6 mm (35-7/16 x 48 x 1/4 inches) plywood
- 1 sheet of 650 x 1200 x 6 mm (25-1/2 x 48 x 1/4 inches) plywood
- 1 sheet of 900 x 1200 x 15 mm (35-7/16 x 48 x 1/4 inches) plywood
- 1 sheet of 500 x 1200 x 15 mm (20 x 48 x 5/8 inches) plywood
- 2 sheets of 750 x 650 x 15 mm (29-1/2 x 25-1/2 x 5/8 inches) plywood
- 4 mm (1/8 inch) router bit for dogbones
For 1220 x 1220 mm (4 x 4 ft) CNC
- 5 sheets of 1200 x 1200 x 6 mm (48 x 48 x 1/4 inches) plywood
- 1 sheet of 1200 x 1200 x 15 mm (48 x 48 x 5/8 inches) plywood
- 2 sheets of 750 x 650 x 15 mm (29-1/2 x 25-1/2 x 5/8 inches) plywood
- 4 mm (1/8 inch) router bit for dogbones
For 1220 x 2440 mm (4 x 8 ft) CNC
- 1 sheet of 1220 x 2440 x 6 mm (48 x 96 x ¼ inches) plywood
- 2 sheets of 1220 x 2440 x 15 mm (48 x 96 x 5/8 inches) plywood
- 1 sheet of 600 x 2000 x 15 mm (23-5/8 x 79 x 5/8 inches) plywood
- 4 mm (1/8 inch) router bit for dogbones

Assembling time

50 minutes
The product may differ from the representative images when cut and assembled. We hope you will enjoy your purchase from Aribabox!
View full details
