Bar Cabinet - Submarine DXF Files
Bar Cabinet - Submarine DXF Files
Regular price
$35.45 USD
Regular price
$35.45 USD
Sale price
$35.45 USD
Unit price
/
per
Taxes included.
Couldn't load pickup availability
Craft your own unique Submarine Bar Cabinet with these CNC router-ready DXF files. Featuring an eye-catching exposed locking mechanism, this stylish cabinet mimics the operation of submarine doors.
Rotate the central wheel to release secure locking pins for a smooth and satisfying cabinet opening experience.
Ideal as a focal point or elegant addition to any interior, this project is both functional and visually stunning.
Supported CNC sizes
Supported CNC sizes
The project can be made on a
800 x 1200 mm (2.6 x 4 ft) CNC
router and bigger.
Max single piece size
Max single piece size
The biggest component is
650
x
850
mm (25.59
x
33.46
inches).
So if it can fit on your CNC router, you can build this project
So if it can fit on your CNC router, you can build this project
Dimensions
Dimensions
| Width | Length | Height |
|---|---|---|
| 650 mm | 430 mm | 1085 mm |
| 25ā inch | 16ā inch | 42Ā¾ inch |
Required materials
Required materials
For a 820 x 1220 mm (2.6 x 4 ft) CNC
For a 820 x 1220 mm (2.6 x 4 ft) CNC
- 6 sheets of 725 x 1220 x 15 mm (28-1/2 x 48 x 5/8 inch) plywood
- 1 sheet of 800 x 1220 x 12 mm (31-1/2 x 48 x 1/2 inch) plywood
- M8 x 55 mm fully-threaded screws - 3 pieces
- M8 x 300 mm threaded rod
- M6 x 30 mm fully-threaded screws - 18 pieces
- M6 x 60 mm screws - 2 pieces
- M8 lock nuts - 7 pieces
- M6 lock nuts - 18 pieces
- M8 washers - 18 pieces
- M6 washers - 40 pieces
- Wood screws - 25 mm (1 inch) - 32 pieces
- Beeswax - for hinges and locking mechanism
For a 900 x 1220 mm (3 x 4 ft) CNC
For a 900 x 1220 mm (3 x 4 ft) CNC
- 4 sheets of 900 x 1220 x 15 mm (36 x 48 x 5/8 inch) plywood
- 1 sheet of 600 x 700 x 15 mm (24 x 28 x 5/8 inch) plywood
- 1 sheet of 800 x 1220 x 12 mm (31-1/2 x 48 x 1/2 inch) plywood
- M8 x 55 mm fully-threaded screws - 3 pieces
- M8 x 300 mm threaded rod
- M6 x 30 mm fully-threaded screws - 18 pieces
- M6 x 60 mm screws - 2 pieces
- M8 lock nuts - 7 pieces
- M6 lock nuts - 18 pieces
- M8 washers - 18 pieces
- M6 washers - 40 pieces
- Wood screws - 25 mm (1 inch) - 32 pieces
- Beeswax - for hinges and locking mechanism
For a 1220 x 1220 mm (4 x 4 ft) CNC
For a 1220 x 1220 mm (4 x 4 ft) CNC
- 3 sheets of 1220 x 1220 x 15 mm (48 x 48 x 5/8 inch) plywood
- 1 sheet of 400 x 700 x 15 mm (16 x 28 x 5/8 inch) plywood
- 1 sheet of 800 x 1220 x 12 mm (31-1/2 x 48 x 1/2 inch) plywood
- M8 x 55 mm fully-threaded screws - 3 pieces
- M8 x 300 mm threaded rod
- M6 x 30 mm fully-threaded screws - 18 pieces
- M6 x 60 mm screws - 2 pieces
- M8 lock nuts - 7 pieces
- M6 lock nuts - 18 pieces
- M8 washers - 18 pieces
- M6 washers - 40 pieces
- Wood screws - 25 mm (1 inch) - 32 pieces
- Beeswax - for hinges and locking mechanism
For a 1220 x 2440 mm (4 x 8 ft) CNC
For a 1220 x 2440 mm (4 x 8 ft) CNC
- 1 sheet of 1220 x 2440 x 15 mm (48 x 96 x 5/8 inch) plywood
- 1 sheet of 600 x 2440 x 15 mm (24 x 96 x 5/8 inch) plywood
- 1 sheet of 800 x 1220 x 12 mm (31-1/2 x 48 x 1/2 inch) plywood
- M8 x 55 mm fully-threaded screws - 3 pieces
- M8 x 300 mm threaded rod
- M6 x 30 mm fully-threaded screws - 18 pieces
- M6 x 60 mm screws - 2 pieces
- M8 lock nuts - 7 pieces
- M6 lock nuts - 18 pieces
- M8 washers - 18 pieces
- M6 washers - 40 pieces
- Wood screws - 25 mm (1 inch) - 32 pieces
- Beeswax - for hinges and locking mechanism
Approximate CNC time
Approximate CNC time
3 hours
Assembling time
Assembling time
4 hours
The product may differ from the representative images when cut and assembled. We hope you will enjoy your purchase from Aribabox!
