5-Drawer Workshop Cabinet - DXF Files

5-Drawer Workshop Cabinet - DXF Files

Regular price $11.45 USD
Regular price $11.45 USD Sale price $11.45 USD
Sale Sold out
Taxes included.

Build your own workshop cabinet with these CNC-ready DXF files.



This 5-drawer workshop cabinet comes in three widths (400mm, 475mm, and 550mm), making it easy to mix, match, and customize your layout.



The design comes with built-in drawer slides that are super simple to install and allow you to save money on metal drawer slides.



Ideal for tool storage, supplies, or gear. Designed for CNC routers - no design work needed.

Perfect for plywood builds - fast, functional, and workshop-friendly.

Supported CNC sizes

The project can be made on a 800 x 1200 mm (2.6 x 4 ft) CNC router and bigger.

Max single piece size

The biggest component is 900 x 550 mm (35.43 x 21.65 inches).
So if it can fit on your CNC router, you can build this project

Dimensions


Minimum

Width Length Height
400 mm 550 mm 900 mm
15¾ inch 21⅝ inch 35⅜ inch

Maximum

Width Length Height
550 mm 550 mm 900 mm
21⅝ inch 21⅝ inch 35⅜ inch

Required materials

For a 820 x 1220 mm (2.6 x 4 ft) CNC:
- 3 sheets of 1220 x 820 x 18 mm (48 x 32 x 3/4 inches) plywood
- 4 sheets of 1220x 820 x 12 mm (48 x 32 x 1/2 inches) plywood
- 6 mm (1/4 inch) router bit
- 35 mm (1-1/4 inch) wood screws
For a 1220 x 1220 mm (4 x 4 ft) CNC:
- 2 sheets of 1220 x 1220 x 18 mm (48 x 48 x 3/4 inches) plywood
- 2 sheets of 1220 x 1220 x 12 mm (48 x 48 x 1/2 inches) plywood
- 1 sheet of 1220 x 600 x 12 mm (48 x 24 x 1/2 inches) plywood
- 6 mm (1/4 inch) router bit
- 35 mm (1-1/4 inch) wood screws
For a 1220 x 2440 mm (4 x 8 ft) CNC:
- 1 sheet of 2440 x 1220 x 18 mm (96 x 48 x 3/4 inches) plywood
- 1 sheet of 2440 x 1220 x 12 mm (96 x 48 x 1/2 inches) plywood
- 1 sheet of 750 x 700 x 12 mm (30 x 28 x 1/2 inches) plywood
- 6 mm (1/4 inch) router bit
- 35 mm (1-1/4 inch) wood screws

Approximate CNC time

45 minutes

Assembling time

40 minutes
The product may differ from the representative images when cut and assembled. We hope you will enjoy your purchase from Aribabox!
